Based on a Linux embedded OS, the Cleber detects the presence of the boards and shows the related control interface to the user, either through:
- a web GUI (Guided User Interface) and
- a Touchscreen TFT display
Two power sources (AC and DC) are always available; for the DC source, customer can chose between 22-65 Vdc or 10-36 Vdc for site or DSNG applications.
Thus Cleber can host any combination of boards, particular applications and use cases can be considered and described separately.
For satellite DVB-S2 contribution to transmitting sites in a TV or radio network, a multistream or single stream receiver is available; the XS4 board, equipped with one L-band input and four ASI outputs. The receiver can be connected with any kind of LNB and it is protected against overvoltage.
The DVB-S2 receiver features a very low end-to-end delay and reduced overall jitter even in multistream configuration (it supports up to 4 ISI simultaneous demodulation); all these features make the CLEBER-XS4 the best solution for distribution and contribution networks to feed TV and Radio Transmitters.
A very intuitive WEB interface lets the user configure and monitor the apparatus very quickly, without requirement of special software.
For further information, write to sales@elber.it
|
